SHINDARO DLEV Golf-C (2+2 Seats) Cross-Country Golf Cart

The SHINDARO DLEV Golf-C is a practical 4-passenger cross-country electric utility cart built to handle varied terrains. The powertrain is highly customizable, allowing you to choose between a 3.5kW, 4kW, or 5kW AC asynchronous motor, paired with a 48V, 60V, or 72V fully intelligent electronic control system. It delivers a reliable maximum speed of 30km/h and a driving range of 70 to 110km on a single charge.

Built on a durable steel frame, the cart features MacPherson independent front suspension (or semi-floating front axle) and an integral rear axle equipped with high-strength steel plate springs and cylinder hydraulic shock absorbers. Fitted with 12-inch off-road tubeless radial tires and providing a 120mm minimum ground clearance, it manages uneven paths with ease. Stopping power is effectively managed by a four-wheel front disc and rear drum hydraulic brake system alongside a dual circuit hydraulic parking brake.

Key Specifications:

• Model: DLEV Golf-C (2+2 seats cross-country)

• Seating Capacity: 4 people

• Dimensions (L x W x H): 2800 x 1240 x 1850 mm

• Motor Options: 3.5kw / 4kw / 5kw AC asynchronous motor

• Battery: Maintenance free battery / lithium battery

• Control System: 48v/60v/72v fully intelligent electronic control

• Max Speed: 30km/h

• Driving Range: 70-110km

• Climbing Ability: 30% maximum climbing slope

• Charging: Vehicle mounted intelligent charger (110-240V input) with 8-9 hours charging time

• Suspension: MacPherson independent front suspension / Integral rear axle with high-strength steel plate spring and cylinder hydraulic shock absorber

• Braking System: Four wheel front disc rear drum hydraulic brake, dual circuit hydraulic parking brake

• Tires: 12-inch off-road tubeless radial tire

• Ground Clearance: 120mm

• Curb Weight: 470 kg
